Container Dimensions







Open-top container at a depot, showing its side, cargo doors and roof tarpaulin.

40ft Open Top Container

Containers for Oversized Cargo

A 40ft open top container is designed for cargo that cannot be loaded conveniently through the end doors of a standard enclosed container. The removable roof arrangement allows machinery, equipment and other awkward loads to be lowered into the container from above.

Shipping Containers of Birmingham supplies 40ft open top containers for logistics, construction and industrial requirements across the Midlands. They can suit tall machinery, timber, scrap metal and other loads where crane access or additional loading clearance is needed.

The container type should be chosen around the cargo dimensions, weight and handling method. A 40ft open top provides substantial length, but the roof opening, internal dimensions and available site access all need to be checked before loading or delivery.

Open-top container at a depot, showing its side, cargo doors and roof tarpaulin.

40ft Open Top Container Dimensions and Capacity

The removable roof system and structural components mean the usable dimensions differ from those of a standard dry container. The measurements below are those stated for the 40ft open top container.

Ready to Start Your Container Project?

Get expert advice on container sales and hire today.

Description Imperial Metric
Maximum Payload 58,643 lb 26,600 kg
External Dimensions 40 ft x 8 ft x 8 ft 6 in 12.192 x 2.438 x 2.591 m
Internal Length 39 ft 5 3/4 in 12.032 m
Internal Width 7 ft 8 5/8 in 2.352 m
Internal Height 7 ft 8 1/2 in 2.348 m
Roof Opening Length 38 ft 8 7/8 in 11.810 m
Roof Opening Width 7 ft 3 7/8 in 2.232 m
Gross Weight 67,197 lb 30,480 kg
Tare Weight 8,422 lb 3,820 kg

Tare weight is the weight of the empty container. Maximum payload is the stated maximum cargo weight, while gross weight is the combined permitted weight of the container and its cargo.

Dimensions can vary slightly between manufacturers. Where machinery or other cargo needs close clearance around the roof opening, doors or internal structure, check the measurements of the individual container before loading.

Open-top container at a depot, showing its side, cargo doors and roof tarpaulin.

How a 40ft Open Top Container Works

The main difference between an open top and a standard 40ft shipping container is the roof. Instead of a fixed steel roof, an open top uses removable roof bows beneath a tarpaulin cover.

Removable Roof Bows and Tarpaulin

The steel roof bows can be removed to create access from above. This allows cranes or other suitable lifting equipment to lower cargo directly into the container.

Once loading is complete, the bows and tarpaulin can be refitted. The tarpaulin provides weather protection when correctly fitted and secured, but it does not provide the same physical security as a fixed steel roof.

Swing-Out Header

Many open top containers use a swinging or removable header above the cargo doors. Moving this header can provide additional clearance for taller items being loaded through the end of the container.

This can be useful for machinery or equipment that cannot pass beneath the fixed header of a standard container. The arrangement should be checked on the particular unit before planning the load around it.

Lashing Points and Flooring

Lashing points are provided to help secure cargo during transport. Heavy machinery and dense materials can create substantial point loads, so weight distribution and restraint need to be planned rather than relying only on the stated maximum payload.

The stated floor construction can vary between units, so any particularly heavy or concentrated load should be assessed against the individual container and proposed handling method.

Loading Oversized and Over-Height Cargo

Open top containers are useful where cargo needs to be lowered from above or where additional height clearance is required during loading. The lifting method should take account of the cargo weight, centre of gravity, available headroom and the usable roof opening.

Cargo should not be assumed to fit simply because its overall dimensions are smaller than the external dimensions of the container. Internal dimensions, roof opening width and length, header position and lifting equipment can all reduce the available clearance.

If cargo extends above the normal roofline, the tarpaulin may not be capable of enclosing it. Over-height cargo can also affect road transport, ship stowage and carrier acceptance, so the proposed movement should be agreed with the relevant transport provider.

40ft or 20ft Open Top Container

The choice between a 40ft and 20ft open top depends on cargo length, weight, site access and how the load will be handled. A 40ft unit provides considerably more length for machinery, timber and other elongated cargo.

A 20ft open top container may be more practical for shorter loads, dense cargo or sites with restricted access. A smaller container also needs less room for positioning and future collection.

Where the main problem is excessive width rather than height, a 40ft flat rack container may be better suited because it does not use conventional side walls.

Condition for Storage and Transport

Open top containers can be available in one-trip and used condition. A one-trip container has normally carried a single cargo journey after manufacture, while a used unit can show dents, paint wear, surface corrosion and evidence of previous repairs.

Wind and watertight is commonly used to describe a storage container intended to keep normal wind and rain from entering through defects in the structure or closures. With an open top, the condition and fit of the tarpaulin also matter.

Wind and watertight condition should not be treated as a guarantee that a container is suitable for international freight. Cargo-worthy status, inspection condition, certification and carrier acceptance need to be considered separately.

HIAB Delivery and Site Access

HIAB means a lorry-mounted hydraulic crane used to lift and position containers. Delivering a 40ft open top requires sufficient space for a large delivery vehicle as well as room for the crane to operate.

Check the complete approach to the site. Narrow entrances, tight corners, parked vehicles and limited turning space can prevent the vehicle reaching the proposed position even where there is enough room for the container itself.

The ground should be firm, stable and reasonably level. Uneven support can put the container frame out of level and make the cargo doors harder to operate. Drainage should also be considered so standing water does not continually collect around the base.

Overhead cables, branches, roofs and other obstructions can restrict crane operation. The achievable placement also depends on crane reach, so lifting over walls or fences needs to be assessed from the actual site layout.

More information on positioning and relocation is available on the container transport and HIAB moves page.

Planning a Long-Term Placement

A shipping container should not automatically be assumed to require or avoid planning permission. Requirements can depend on how the unit will be used, how long it will remain on site and the status of the property.

Visibility, neighbouring properties, listed status, conservation areas and a possible change of use can all be relevant. Where the planning position is uncertain, check current requirements with the relevant local council before placement.

Lease conditions, landlord approval and site-management rules may also apply independently of planning control.

Using a 40ft Open Top for Export

CSC refers to the International Convention for Safe Containers. A container intended for international freight needs appropriate CSC approval and inspection status for the proposed movement.

Over-height or otherwise out-of-gauge cargo can require different handling and stowage arrangements from cargo contained fully within the normal container profile. Carrier acceptance should therefore be confirmed before loading.

VGM means Verified Gross Mass and relates to the verified weight of a packed container for sea transport. Export movements can also involve customs documents, Incoterms, insurance, tax considerations and possible detention or demurrage charges.

Requirements vary between cargoes, routes and carriers. Check legal, customs, tax, insurance and shipping requirements with the relevant authority, carrier or professional adviser. The Shipper's Own Container guide covers further points for containers used in international transport.

Buying or Hiring a 40ft Open Top Container

Buying can suit long-term logistics, repeated industrial use or storage where ownership is useful. It also gives greater control over future use, although structural changes should be considered carefully if the container may later return to freight service.

Hire can work better where an open top is required for a temporary project. Before hiring, confirm the permitted use, collection arrangements, responsibility for damage and whether the unit can be relocated during the hire period.

Shipping Containers of Birmingham provides containers to buy and container hire across its service area. For a specific 40ft open top and delivery requirement, use the container price enquiry.
